The french B2B IoT startups landscape is available and rich !

Wavestone has just published the 2019 French IoT B2B startup landscape

https://fr.wavestone.com/fr/insight/radar-wavestone-startups-iot-b2b/

Charts full size for better analysis

take benefit of the full screen chart to make more relevant analysis

Firmware upgrade guide

You must have a HummBox firmware upgrade OTA (over the air) and follow the tutorial:

https://docs.google.com/document/d/1WpJvVVhWsooK2FFzjShqVnvbeeFrLFZAN7RiGvjxhPM/edit?usp=sharing

Device management & admin principles

General overview

User role regarding device life cycle

Who’s working where

Manage measurement anomalies

You can now manage anomalies from the charts or list of measures.



Tagged anomalies are hidden from the chart in normal mode. Anomalies in the list are tagged with a pictogram.

Note : automatic anomaly detection will be available soon

Device management log

Device management items feed a log in device profile

Calibration process for HummBox Air Indoor

There are 3 calibration methods.

Fresh air

(To be done before installing a device)

  1. Put the HummBox outside in a safe place (no rain…)
  2. Wait about 2 minutes (10 minutes if the box was previsously exposed to a big difference of temperature) and press the button 8 seconds
  3. Wait 1 minutes and enforce a measurement, by pressing the button
  4. Check the value is around 400 ppm

Manual

Pre requisite: Know the environment CO2 value

  1. Put the HummBox in an environment you can know the CO2 level
  2. Enter the known value in the device settings for manual calibration
  3. Press the button twice
  4. Wait 1 minutes and enforce a measurement, by pressing the button
  5. Check the value is around the know CO2 value

Automatic

Automatic calibration is done every 10 days to prevent from sensor deviation.

/!\ The device has be in an environment reaching down 400 ppm at least once a week. If not, platform configuration is necessary

HummBox AirIndoor Office installation guide

OVERVIEW



QUICK INSTALLATION GUIDE

1. Wakeup HummBox using button

2. Check device availability in the App / Register it
https://app.humm-box.com
If device is not listed in the app, add it using “+ Add a device” button

and type its ID located on the sticker
example : GCZ – 4317 – RCZ1 – 00205C43

/!\ Some device settings maybe necessary for indicators / KPI data shaping. See device settings tab in the App

3. Check automatic 1rst message by refreshing the App, about 1 minute after wakeup

4. Run calibration process

see dedicated procedure

HummBox Level Compact IP68 installation guide

OVERVIEW



QUICK INSTALLATION GUIDE

1. Plug the antenna



2. Wakeup HummBox using magnet

3. Check device availability in the App / Register it
https://app.humm-box.com
If device is not listed in the app, add it using “+ Add a device” button

and type its ID located on the sticker
example : GCZ – 4317 – RCZ1 – 00205C43

/!\ Some device settings maybe necessary for indicators / KPI data shaping. See device settings tab in the App

4. Check automatic 1rst message by refreshing the App, about 1 minute after wakeup

HummBox Wired installation guide

OVERVIEW



QUICK INSTALLATION GUIDE

1. Plug the antenna

2. Wakeup HummBox using button

3. Check device availability in the App / Register it
https://app.humm-box.com
If device is not listed in the app, add it using “+ Add a device” button

and type its ID located on the sticker
example : GCZ – 4317 – RCZ1 – 00205C43

/!\ Some device settings maybe necessary for indicators / KPI data shaping. See device settings tab in the App. For HummBox Soil, please refer to specific calibration process here.

4. Check automatic 1rst message by refreshing the App, about 1 minute after wakeup
